In addition to the elements on either side of the short edge, elements that use one of the nodes of the short edge may also be affected. A tria element along the short edge will typically be deleted. Typically, a quad element along the short edge will become a tria. To create replacement patterns, the short edge is collapsed to a node. If an edge of the resulting pattern is still too small, however, replacement patterns may be created. These embodiments involve a computing device configured for receiving a finite element mesh in electronic format, for receiving input specifying at least one quality threshold value for two or more element quality parameters, calculating a quality score for at least one element within the finite element mesh to identify at least one element whose quality score does not meet the quality threshold values for the two or more element quality parameters, creating at least one substitute element for the at least one element whose quality score does not meet the quality threshold values, calculating a quality score for each of the substitute elements and, if any of the substitute elements have a better quality score than the elements whose quality score does not meet the quality threshold values, replacing elements whose quality score does not meet the quality threshold value with the substitute element(s) having the best quality score.
Other embodiments of the present invention include a computer-implemented method and system for replacing certain elements in a finite element mesh to improve the quality of the mesh.
wire-frame surface description, tesselation G06T17/20- Finite element generation, e.g.G06T17/00- Three dimensional modelling, e.g.G06T- IMAGE DATA PROCESSING OR GENERATION, IN GENERAL.238000002360 preparation method Methods 0.000 description 2.230000001276 controlling effect Effects 0.000 description 2.238000006243 chemical reaction Methods 0.000 description 2.241000321453 Paranthias colonus Species 0.000 description 2.238000004364 calculation method Methods 0.000 description 4.Publication of US20040119711A1 publication Critical patent/US20040119711A1/en Priority to US11/242,690 priority patent/US7295205B2/en Application granted granted Critical Publication of US6970165B2 publication Critical patent/US6970165B2/en Status Expired - Fee Related legal-status Critical Current Adjusted expiration legal-status Critical Links Assignors: KINNEY, PAUL RICHARD, WOLLNY, MARTIN R. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.) Filing date Publication date Application filed by Ford Motor Co filed Critical Ford Motor Co Priority to US10/248,115 priority Critical patent/US6970165B2/en Assigned to FORD MOTOR COMPANY reassignment FORD MOTOR COMPANY ASSIGNMENT OF ASSIGNORS INTEREST (SEE DOCUMENT FOR DETAILS). Original Assignee Ford Motor Co Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation or warranty as to the accuracy of the list.) Wollny Paul Richard Kinney Current Assignee (The listed assignees may be inaccurate. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.) Expired - Fee Related, expires Application number US10/248,115 Other versions US20040119711A1
ASPECT RATIO CALCULATOR FEM PDF
Google Patents Method and system for optimizing a finite element meshĭownload PDF Info Publication number US6970165B2 US6970165B2 US10/248,115 US24811502A US6970165B2 US 6970165 B2 US6970165 B2 US 6970165B2 US 24811502 A US24811502 A US 24811502A US 6970165 B2 US6970165 B2 US 6970165B2 Authority US United States Prior art keywords quality mesh quality score elements finite element Prior art date Legal status (The legal status is an assumption and is not a legal conclusion. Google Patents US6970165B2 - Method and system for optimizing a finite element mesh US6970165B2 - Method and system for optimizing a finite element mesh
